9.1 General Specifications
Averaging No. of samples to
average
2 to 100, OFF
Averaging
method
Integrating average
However, with external triggering and continuous measurement
ON (Free-Run), the default averaging method is Moving
Average
Average (of measurements D1 to D6) with Averaging Samples set to 2.
1st Sample 2nd Sample 3rd Sample
Free-Run (Moving Avg.) (D1+D2)/2 (D2+D3)/2 (D3+D4)/2
Non-Free-Run (integrating Avg.) (D1+D2)/2 (D3+D4)/2 (D5+D6)/2
Statistical calculation Setting ON or OFF
Calculations Total Data Count, Mean, Minimum Value (serial no.), Maximum
Value (serial no.), Standard Deviation of Sample, Overall
Standard Deviation, Process Capability Indices
Data importing Statistical calculation occurs by any of the following:
TRIG key, EXT I/O TRIG
terminal, ∗TRG or GET command
Data count Up to 30000
Key-Lock function ON or OFF
Remote/Local function Operation When RS-232C or GP-IB communication is enabled, REMOTE
is lit.
Pressing the SHIFT
→AUTO keys switches from Remote to
Local operation
Line frequency setting 50 or 60 Hz
SAVE/LOAD Storage capacity (No. of sets of settings) 30
Saved settings
• Measurement functions
• Resistance Measurement
Range
• Low-Power Resistance
Measurement Range
• Zero-Adjust ON/OFF
•Zero-Adjust Value
• Temp. Correction Function
ON/OFF
• Reference Temperature
• Temperature Coefficient
• Temp. Conversion Function
ON/OFF
• Initial Resistance
• Initial Temperature
•Constant
• Statistical Calculation ON/OFF
• Sampling rate
• Self-Calibration AUTO/
MANUAL
• Offset Voltage Compensation
ON/OFF
• Trigger Setting INT/EXT
• Delay AUTO/MANUAL
• Delay (time value)
• Averaging ON/OFF
• No. of samples to average
• Key-Lock
• Comparator ON/OFF
• Comparator Beeper
• Comparator Thresholds
• Comparator Comparison
Method
• BIN ON/OFF
• Each BIN No. ON/OFF
• BIN Thresholds
• BIN Comparison Method
• External I/O BIN/BCD
• Measurement Fault SYNC or
ASYNC
