9.1 General Specifications
160
Zero-Adjust function Zero-Adjust range 1,000 dgt in each range
Sampling rate SLOW2, SLOW1, MEDIUM or FAST
Self-Calibration Function
Function (MEDIUM and
FAST sampling)
(Occurs at power-on, and
after switching
measurement settings)
AUTO MEDIUM and FAST
Self-calibration occurs every 30 minutes
SLOW2 and
SLOW1
Self-calibration occurs at every sample
MANUAL MEDIUM and FAST Self-calibration upon input from EXT I/O terminal
SLOW2 and
SLOW1
Self-calibration occurs at every sample
Measurement fault
detection
Function Open-circuit SOURCE and SENSE wiring and constant-current
faults can always be observed.
ERR output is present at the EXT I/O terminal when a
measurement fault is detected
ErrCurr is displayed when the SOURCE line is open
ErrHi is displayed when the SENSE-H line is open
ErrLo is displayed when the SENSE-L line is open
Output timing SYNC or ASYNC
SYNC: Synchronous with EOC output
ASYNC: Asynchronous with EOC output
Overflow detection
function
OF or -OF appears when input exceeds the specified display range
Offset Voltage
Compensation function
ON or OFF
Trigger function Internal trigger Triggering occurs internally when a measurement is finished
External trigger EXT.TRIG appears
Triggering occurs by any of the following:
TRIG key, EXT I/O TRIG
terminal, ∗TRG or GET command
When :INITIATE:CONTINUOUS is OFF, an :INITIATE command must be sent
before triggering.
Delay function
AUTO
AUTO or MANUAL
Normal resistance measurement (Offset Voltage Compensation OFF)
Normal resistance measurement (Offset Voltage Compensation ON)
Low-Power mode (Offset Voltage Compensation OFF)
Low-Power mode (Offset Voltage Compensation ON)
MANUAL Delay: 0.000 to 9.999s
Range [Ω]
20 m 200 m 2 20 200 2 k 20 k 100 k 1 M 10 M 100 M
Delay [ms]
30 30 3 3 3 3 3 10 100 500 1000
Range [Ω]
20 m 200 m 2 20 200 2 k 20 k
Delay [ms]
100 100 100 100 100 100 100
Range [Ω]
2 20 200 2 k
Delay [ms]
33315
Range [Ω]
2 20 200 2 k
Delay [ms]
100 100 100 100
