Appendix 6 Test Lead Options
9454 ZERO ADJUSTMENT BOARD
The Zero-Adjust board is used to provide zero-
adjustment when using the 9461 PIN TYPE LEAD
and 9465 PIN TYPE LEAD. This board has a 2-layer
structure consisting of a printed board and steel plate,
so the pin-type leads can be shorted together only by
pressing the pin tips into the specified contact holes.
This board is not used for the 9465 PIN TYPE LEAD.
Dimensions: 214W x 24H x 8D mm
