4.2 Measurement Range Setting
Range Displayed Values
Resistance Measurement
Function
Low Power Resistance
Measurement Function
Measurement
Current
Open-Terminal
Voltage
Measurement
Current
Open-Terminal
Voltage*
20mΩ 20.0000 to -0.2000 mΩ 1 A ±5% 5 Vmax
−−−−−−−−− −−−−−−−−−
200mΩ 200.000 to -2.000 mΩ 1 A ±5% 5 Vmax
−−−−−−−−− −−−−−−−−−
2Ω 2000.00 to -20.00 mΩ 100 mA ±5% 2.6 Vmax 10 mA ±5% 60 mVmax
20Ω 20.0000 to -0.2000
Ω
10 mA ±5% 2.6 Vmax 1 mA ±5% 60 mVmax
200Ω 200.000 to -2.000
Ω
10 mA ±5% 2.6 Vmax 100 µA ±5% 60 mVmax
2kΩ 2000.00 to -20.00
Ω
1 mA ±5% 2.6 Vmax 10 µA ±5% 60 mVmax
20kΩ 20.0000 to -0.2000 kΩ 100 µA ±5% 2.6 Vmax
−−−−−−−−− −−−−−−−−−
100kΩ 110.000 to -2.000 kΩ 100 µA ±5% 13 Vmax
−−−−−−−−− −−−−−−−−−
1MΩ 1100.00 to -20.00 kΩ 10 µA ±5% 13 Vmax
−−−−−−−−− −−−−−−−−−
10MΩ 11.0000 to -0.2000 MΩ 1 µA ±5% 13 Vmax
−−−−−−−−− −−−−−−−−−
100MΩ 110.000 to -2.000 MΩ 100 nA ±5% 13 Vmax
−−−−−−−−− −−−−−−−−−
* When using external triggering, open-terminal voltage is limited to 20 mV maximum from when INDEX goes
High until the next trigger input.
