61
5.5 Temperature Conversion Function (
∆
t)
Setting the Conversion Constant
1
(SHIFT Lamp lit)
The constant setting display appears.
2
Set the reciprocal (k) of the temperature coefficient at 0°C, initial
resistance (R1) and initial temperature (t1).
k Reference Value
Recommended by IEC60034 as follows:
• Copper: k = 235
• Aluminum: k = 225
❖ Reference (Page 171)
3
Applies setting and returns to the Measurement display.
To cancel the settings:
Or ten-keys
Initial temperature (t1) [-10.0 to 99.9°C]
Reciprocal (k) of the temperature coefficient at 0°C
(-999.9 to 999.9)
(Sub Display)
(Main Display)
Initial resistance (R1) [0 mΩ to 110 MΩ]
Enabling/Disabling Temperature Conversion
∆t lit...........Temperature Conversion enabled.
∆t off..........Temperature Conversion disabled.
