12.3 Remote Control of the Instrument by Internet Browser
184
The instrument includes a standard HTTP server function that supports remote control by an internet
browser on a computer.
The instrument's display screen and control panel keys a
re emulated in the browser. Operating proce-
dures are the same as on the instrument.
Launch Internet Explorer
®
, and enter "http://" followed by the IP address assigned to the instrument in the
browser's address bar.
For example, if the instrument's IP address
is 172.19.112.160, enter as follows.
A main page such as the following will be displayed when the
browser has successfully connected to the
instrument:
12.3 Remote Control of the Instrument by Inter-
net Browser
• It is recommended to use either Microsoft
®
Internet Explorer
®
version 8 or later or Apple
Safari version 5.0 or later.
• Only one computer can be connected at a time.
• Set the browser security level to “Medium” or “Medium-high,” or enable Active Scripting
set
tings.
• Unintended operations may occur if remote control is attempted from multiple computers
simu
ltaneously. Use one computer at a time for remote control.
• Remote control can be performed even if the instrument
's key lock is active.
Connecting to the Instrument
Enter "http://IP Address/".
If no HTTP screen is displayed
1. Perform this procedure.
(1) Click [Tools]-[Internet Options] to display Internet Explorer
®
settings.
(2) On the [Advanced] tab, under HTTP 1.1 settings, enable [Use HTTP1.1] and disable [Use
HTTP1.1 through proxy connections].
(3) On the [Connections] tab, click [LAN Settings], and disable [Use a proxy server].
2. LAN communications may not be possible.
(1) Check the network settings on the instrument and the IP address of the computer.
See: "LAN Settings and Network Environment Configuration" (p.180)
(2) Check that the LINK LED in the Ethernet internet jack is lit, and that (the LAN indicator) is
displayed on the instrument's screen.
See: "Instrument Connection" (p.182)
To Next Page
