5.8 Factory Settings
93
Chapter 5 Changing Settings (as necessary)
5
All settings’ default values are as follows:
5.8 Factory Settings
Measurement settings
Setting Default value Setting Default value
Wiring
CH123: 3P4W
CH4: AC+DC
Current sensor
CH123: CT7136
CH4: CT7136
Phase Name RST I Range
CH123: 500 A
CH4: 500 A
VT ratio
CH123: 1
CH4: 1
CT ratio
CH123: 1
CH4: 1
Declared input voltage 230 V THD Type THD-F
Frequency 50 Hz Harm Calc U,I,P: All Levels
Urms Type Phase-N Flicker
Varies with set display
language.
PF Type PF
Measurement period and recording settings
Setting Default value Setting Default value
Time Start Exactly TIME PLOT interval 1 min
Repeat Record OFF Screen copy interval OFF
Recording Items All data
Hardware settings
Setting Default value Setting Default value
Language Set language LCD Backlight ON
Display color Color 1 External output Short pulse
Beep sound ON External control (IN) Event
RS-232C connection OFF
Vector area settings
Setting Default value Setting Default value
Phase area ±30 U/I phase difference 0
Amplitude area ±20
