5.2 Changing the Recording Settings
75
Chapter 5 Changing Settings (as necessary)
5
Estimated data
(TIME PLOT)
Depending on the settings, Displays an estimate of the amount of data that will
be saved. The estimated data volume is calculated based on the recording item,
TIME PLOT interval, real-time control, and repeated recording settings. The esti-
mated data volume does not include scr
een copy data or event data.
If the data volume exceeds the amount of space remaining on the SD card, the
value will be show
n in red. Either free up space on the card by deleting
unneeded data or replace the card with one with more space.
SD Card available
capacity
Displays the amount of space remaining on the SD memory card. If the SD
memory card experiences an error, "SD Error" will be shown.
Saveable measure-
ment time
Displays an estimate of how many days of data can be saved based on the esti-
mated data volume and the SD card remaining capacity. The actual number of
da
ys of data that can be saved may be less than the indicated amount depend-
ing on the number of screen copies mad
e and events generated.
5.2 Changing the Recording Settings
Display the
pull-down menu
Select a setting
Accept setting
Cancel
[Record]
[SYSTEM] screen
Select a setting
Key operation during configuration
[Interval]
To Next Page
