13.7 Other Functions
230
13.7 Other Functions
-1. Warning functions
Wiring check Checks connections and current sensor reverse connections as well as phase order on the con-
nection diagram screen.
Out of range When the input exceeds the range by 130%, displays - - - - -.
Out of crest factor When the waveform peak exceeds 2 times the voltage range or 4 times the current range, "crest
factor exceeded" is displayed.
Event check Displays event icons when events occur.
Power supply status display,
Charge status display,
Battery strength display
See: "4 Power supply status display" (p.29)
-2. Settings confirmation function
Function description Press the ESC key during recording (including while in standby mode) to check the present set-
tings.
-3. Screen copy
Function description Pressing the COPY key causes the instrument to store the screenshot displayed at the time onto
the SD memory card.
Data form Compressed BMP format
File names Auto generated, extension of “.bmp”
-4. Special key operation
Key lock function Disables all key operation except for POWER switch and key lock cancelation.
Press and hold ESC key from at least 3 s to turn the function on and off.
Display hold Retains displayed values excluding the time
-5. Action in the event of an anomaly
Action in the event of a power
outage
With Model Z1003 Battery Pack sufficiently charged, the instrument starts to be powered by Model
Z1003, allowing continuous recording.
With Model Z1003 Battery Pack drained, the instrument stops recording. The settings used at the
time ar
e backed up; however, integrated values are discarded.
When power is then recovered, the instrument starts recording and accumulating data anew in the
previous settings.
-6. Setup functionality
Function description Sets the language when the instrument is turned on for the first time.
Boot key reset Reverts all settings, including the language setting, to the factory defaults.
Turn on the instrument while holding down the ENTER and ESC keys
.
