13.9 Range Breakdown and Combination Accuracy
247
10
13
Chapter 13 Specifications
-8. When using the CT7116 AC Leakage Current Sensor
Each channel has the same ranges as 1P2W.
*: When the measurement frequency (f) satisfies th
e following condition: 45 ≤ f≤ 66 (Hz)
Power range breakdown (SUM)
Wiring
Current range
500.00 mA 5.0000 A
1P2W 300.00 5.0000 k
1P3W
3P3W2M
3P3W3M
600.00 10.000 k
3P4W
3P4W2.5E
0.9000 k 15.000 k
Combination accuracy
Current range Current RMS value* Active power*
5.0000 A 1.1% rdg.+0.16% f.s. 1.2% rdg.+0.16% f.s.
500.00 mA 1.1% rdg.+0.7% f.s. 1.2% rdg.+0.7% f.s.
HIOKI PQ3198A961-02
