6. Remove the 17 screws shown in the following
diagram and remove the upper chassis.
7. Insert the tweezers between the battery
holder and the battery and lift up the
battery to remove it.
Lithium
battery
Upper
chassis
CALIFORNIA, USA ONLY
Perchlorate Material - special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
