3.5 Inserting (Removing) an SD Memory Card
44
Insert and remove SD memory cards as follows:
• The operating lifetime of the SD memory card is limited by its flash memory. After
long-term or frequent usage, data reading and writing capabilities will be degraded. In
that case, replace the card with a new one.
• The SD memory card operation indicator (p.28) will turn red while the card is being
accessed.
Turn off the instrument.( p.48)
1
Insert the card horizontally. Inserting the SD memory
card at an angle may cause the writeprotect lock to
engage, preventing data from being written to the
card.
Close the cover.
3
Open the cover.
2
Lock key
Disengage the lock.
4
Insert the SD memory card inside.
5
How toHow to remove:
Open the cover, push in the SD memory
card and
then pull it out.
When storing the data to the SD memory card,
configure the recording settings.
See: "5.2 Changing the Recording Settings" (p.75)
Be sure to close the SD memory
card slot cover.
