4.6 Verifying Correct Wiring (Connection Check)
65
Chapter 4 Configuring the Instrument before Measurement (SYSTEM - SYSTEM screen) and
Wiring
4
Voltage vectors:
• Check that the voltage measurement clips are attached to the lines
according to the wiring diagram.
Current vectors:
• Check that the current sensors are attached to the lines according to the
wiring diagram.
In this case Check
If vector direction (phase) or col-
or is incorrect.
