5.4 Changing Hardware Settings
83
Chapter 5 Changing Settings (as necessary)
5
External control (IN)
Selects whether to use external control (IN) as an event trigger or START/STOP signal.
RS-232C connection
Set when connecting the PQ3198 to Model PW9005 GPS Box with an RS-232C cable.
Setting Contents:( ∗ : Default setting)
Event∗
Use as an event trigger.
START/STOP Use to start and stop recording.
Setting Contents:( ∗ : Default setting)
OFF∗
Disables the RS connection.
GPS
Outputs data to a Model PW9005 GPS Box. If select-
ing this setting, select the time zone. (-13:00 to +13:00)
See: Mo
del PW9005 Instruction manual
