1.1 System Monitor

The system monitor enables you to

X select the software to be loaded

X perform a software update

X start the selected software

X shut down the system monitor

X delete the configuration saved and

X display the boot code information.

 Opening the system monitor

 Use the terminal cable (see accessories) to connect

– the V.24 socket (RJ11) to

– a terminal or a COM port of a PC with terminal emulation based on

VT100

(for the physical connection, see the "Installation" user manual).

 Start the terminal program on the PC and set up a connection with the

device.

When you boot the device, the message

"Press <1> to enter System Monitor 1"

appears on the terminal.

Speed 9,600 Baud

Data 8 bit

Parity none

Stopbit 1 bit

Handshake off

Table 1: Data transfer parameters
