Hirschmann RS20 User Manual

Operation Diagnosis
196
9.6 Displaying the SFP Status
Basic Configuration
Release 6.0 07/2010
9.6 Displaying the SFP Status
The SFP status display allows you to look at the current SFP module
connections and their properties. The properties include:
X module type
X support provided in media module
X Temperature in ºC
X Tx Power in mW
X Receive power in mW
 Select the Diagnostics:Ports:SFP Modules dialog.
Figure 55: SFP Modules dialog

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
