Hirschmann RS20 User Manual

Entering the IP Parameters
Basic Configuration
Release 6.0 07/2010
2.5 System configuration via BOOTP
41
2.5 System configuration via
BOOTP
When it is started up via BOOTP (bootstrap protocol), a device receives its
configuration data in accordance with the “BOOTP process” flow chart (see
fig. 13).
Note: In its delivery state, the device gets its configuration data from the
DHCP server.
 Activate BOOTP to receive the configuration data (see on page 50 “Web-
based IP Configuration“), or see the CLI:
 Provide the BOOTP server with the following data for a device:
# /etc/bootptab for BOOTP-daemon bootpd
#
# gw -- gateway
# ha -- hardware address
# ht -- hardware type
# ip -- IP address
# sm -- subnet mask
# tc -- template
.global:\
:gw=0.0.0.0:\
:sm=255.255.240.0:
enable Switch to the Privileged EXEC mode.
network protocol bootp Activate BOOTP.
copy system:running-config
nvram:startup-config
Activate BOOTP.
y Confirm save.

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
