Hirschmann RS20 User Manual

Configuring the Ports
Basic Configuration
Release 6.0 07/2010
73
5 Configuring the Ports
The port configuration consists of:
X Switching the port on and off
X Selecting the operating mode
X Activating the display of connection error messages
X Configuring Power over ETHERNET.
 Switching the port on and off
In the state on delivery, all the ports are switched on. For a higher level of
access security, switch off the ports at which you are not making any
connection.
 Selecting the operating mode
In the state on delivery, all the ports are set to the “Automatic
configuration” operating mode.
Note: The active automatic configuration has priority over the manual
configuration.
 Select the
Basics:Port Configuration dialog.
 In the "Port on" column, select the ports that are connected to
another device.
 Select the
Basics:Port Configuration dialog.
 If the device connected to this port requires a fixed setting
– select the operating mode (transmission rate, duplex mode) in
the "Manual configuration" column and
– deactivate the port in the "Automatic configuration" column.

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
