Hirschmann RS20 User Manual

Network Load Control
Basic Configuration
Release 6.0 07/2010
8.3 Rate Limiter
139
8.3.3 Rate Limiter settings for
RS20/RS30/40, MS20/MS30, RSR20/RSR30,
MACH 100, MACH 1000 and OCTOPUS
 Select the Switching:Rate Limiter dialog.
X "Ingress Limiter (kbit/s)" allows you to enable or disable the input
limiting function for all ports.
X "Egress Limiter (Pkt/s)" allows you to enable or disable the
broadcast output limiter function at all ports.
X "Egress Limiter (kbit/s)" allows you to enable or disable the output
limiter function for all packet types at all ports.

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
