MACH 100

Release

07/09

Figure 13: 2-pin terminal block

Note: Please note the electrical ratings for the signal contact (see on

page 35 „General technical data“).

Note: Relevant for North America:

The tightening torque of the terminal block screws is 0,34 Nm (3 lb in).

 Mount the terminal block for the signal contact on the front of the

device using the screw locking. Check whether the terminal block is

mounted correctly and screwed on.

2.1.5 Dimension drawings

FAULT

482,6

231,89

312,5

31,75

43,8

465,9
