Hirschmann RS20 User Manual

Operation Diagnosis
Basic Configuration
Release 6.0 07/2010
9.9 Detecting IP Address Conflicts
205
9.9.3 Displaying ACD
 Select the
Diagnostics:IP Address Conflict Detection dialog.
X In the table the device logs IP address conflicts with its
IP address.
For each conflict the device logs:
X the time
X the conflicting IP address
X the MAC address of the device with which the IP address
conflicted.
For each IP address, the device logs a line with the last conflict that
occurred.
 You can delete this table by restarting the device.
Figure 57: IP Address Conflict Detection dialog

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
