Hirschmann RS20 User Manual

Operation Diagnosis
Basic Configuration
Release 6.0 07/2010
9.1 Sending Traps
179
9.1.3 Configuring Traps
 Select the Diagnostics:Alarms (Traps) dialog.
This dialog allows you to determine which events trigger an alarm (trap)
and where these alarms should be sent.
 Select “Create entry”.
 In the “IP Address” column, enter the IP address of the recipient to
whom the traps should be sent.
 In the “Active” column, you select the entries which should be taken
into account when traps are being sent.
 In the “Selection” frame, select the trap categories from which you
want to send traps.
Note: You need read-write access for this dialog.
Figure 49: Alarms dialog

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
