Loading/saving settings
62
3.2 Saving settings
Basic Configuration
Release 6.0 07/2010
3.2.4 Saving as a script on the PC
The device allows you to save the current configuration data in an editable
and readable file on your PC.
 In the save dialog, enter the name of the file in which you want the
device to save the configuration file.
 Click "Save".
 Select the
Basics: Load/Save dialog.
 In the "Save" frame, click "on the PC (script)".
 In the save dialog, enter the name of the file in which you want the
device to save the configuration file.
 Click "Save".

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
