Hirschmann RS20 User Manual

Operation Diagnosis
Basic Configuration
Release 6.0 07/2010
9.1 Sending Traps
177
9.1.1 List of SNMP Traps
All the possible traps that the device can send are listed in the following table.
Trap name Meaning
authenticationFailure is sent if a station attempts to access the agent without permission.
coldStart is sent for both cold and warm starts during the boot process after
successful management initialization.
hmAutoconfigAdapterTrap is sent when AutoConfiguration AdapterACA is removed or
plugged in.
linkDown is sent if the link to a port is interrupted.
linkUp is sent as soon as the link to a port is re-established.
hmTemperature is sent if the temperature exceeds the set threshold values.
hmPowerSupply is sent if the status of the voltage supply changes.
hmSigConRelayChange is sent if the status of the signal contact changes during the
operation monitoring.
newRoot is sent if the sending agent becomes the new root of the spanning
tree.
topologyChange is sent if the transmission mode of a port changes.
risingAlarm is sent if an RMON alarm input exceeds the upper threshold.
fallingAlarm is sent if an RMON alarm input falls below the lower threshold.
hmPortSecurityTrap is sent if a MAC/IP address is detected at the port which does not
correspond to the current settings of:
– hmPortSecPermission and
– hmPorSecAction is set to either trapOnly (2) or portDisable (3).
hmModuleMapChange is sent if the hardware configuration is changed.
hmBPDUGuardTrap is sent if a BPDU is received at a port when the BPDU Guard
function is active.
hmMrpReconfig is sent if the configuration of the MRP-Ring changes.
hmRingRedReconfig is sent if the configuration of the HIPER-Ring changes.
hmRingRedCplReconfig is sent if the configuration of the redundant ring/network coupling
changes.
hmSNTPTrap is sent if errors occur in connection with the SNTP (e.g. server
cannot be reached).
hmRelayDuplicateTrap is sent if a duplicate IP address is detected in connection with
DHCP Option 82.
lldpRemTablesChangeTra
p
is sent if an entry in the topology remote table is changed.
hmConfigurationSavedTra
p
is sent after the device has successfully saved its configuration
locally.
hmConfigurationChangedT
rap
is sent when you change the configuration of the device for the first
time after it has been saved locally.
Table 22: Possible traps

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
