Operation Diagnosis
194
9.5
Event Counter at Port Level
Basic Configuration
Release
6.0
07/2010
X Collisions, late collisions: In full-duplex mode, the port does not count
collisions or late collisions.
X CRC error: The device only evaluates these errors as duplex problems
in the manual full duplex mode.
Activating the detection
No. Autonegotiati
on
Current
duplex
mode
Detected error
events (≥ 10)
Evaluation of
duplex
situation by
device
Possible causes
1 On Half duplex None OK
2 On Half duplex Collisions OK
3 On Half duplex Late collisions Duplex problem
detected
Duplex problem, EMI,
network extension
4 On Half duplex CRC error OK EMI
5 On Full duplex None OK
6 On Full duplex Collisions OK EMI
7 On Full duplex Late collisions OK EMI
8 On Full duplex CRC error OK EMI
9 Off Half duplex None OK
10 Off Half duplex Collisions OK
11 Off Half duplex Late collisions Duplex problem
detected
Duplex problem, EMI,
network extension
12 Off Half duplex CRC error OK EMI
13 Off Full duplex None OK
14 Off Full duplex Collisions OK EMI
15 Off Full duplex Late collisions OK EMI
16 Off Full duplex CRC error Duplex problem
detected
Duplex problem, EMI
Table 25: Evaluation of non-matching of the duplex mode
Select the Switching:Global dialog.
Select “Enable duplex mismatch detection”. The device then checks
whether the duplex mode of a port might not match that of the
remote port.
If the device detects a potential mismatch, it creates an entry in the
event log and sends an alarm (trap).
enable Switch to the Privileged EXEC mode.
configure Switch to the Configuration mode.
