Hirschmann RS20 User Manual

Operation Diagnosis
208
9.11 Reports
Basic Configuration
Release 6.0 07/2010
 Click “Download Switch-Dump”.
 Select the directory in which you want to save the switch dump.
 Click “Save”.
The device creates the file name of the switch dumps automatically in
the format <IP address>_<system name>.zip, e.g. for a device of the
type PowerMICE: “10.0.1.112_PowerMICE-517A80.zip”.
 Click “Download JAR-File”.
 Select the directory in which you want to save the applet.
 Click “Save”.
The device creates the file name of the applet automatically in the format
<device type><software variant><software version)>_<software
revision of applet>.jar, e.g. for a device of type PowerMICE with software
variant L3P: “pmL3P06000_00.jar”.

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
