Hirschmann RS20 User Manual

General Information
Basic Configuration
Release 6.0 07/2010
B.1 Management Information Base
(MIB)
241
The following abbreviations are used in the MIB:
Comm Group access rights
con Configuration
Descr Description
Fan Fan
ID Identifier
Lwr Lower (e.g. threshold value)
PS Power supply
Pwr Power supply
sys System
UI User interface
Upr Upper (e.g. threshold value)
ven Vendor = manufacturer (Hirschmann)
Definition of the syntax terms used:
Integer An integer in the range -2
31
- 2
31
-1
IP Address xxx.xxx.xxx.xxx
(xxx = integer in the range 0-255)
MAC Address 12-digit hexadecimal number in accordance with ISO/IEC 8802-3
Object identifier x.x.x.x… (e.g. 1.3.6.1.1.4.1.248…)
Octet string ASCII character string
PSID Power supply identifier
(number of the power supply unit)
TimeTicks Stopwatch,
Elapsed time (in seconds) = numerical value / 100
Numerical value = integer in range 0-2
32
-1
Timeout Time value in hundredths of a second
Time value = integer in range 0-2
32
-1
Type field 4-digit hexadecimal number in accordance with ISO/IEC 8802-3
Counter Integer (0-2
32-1
), whose value is increased by 1 when certain events occur.

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
