Hirschmann RS20 User Manual

36
MACH 100
Release 07/09
 Network range
EN 61000-4-5 Voltage surges
- Power line, line/line:
- Power line, line/earth
- Data line
1 kV
2 kV
4 kV
EN 61000-4-6 Line-conducted interference voltages
150 kHz - 80 MHz 10 V
EMC emitted inter-
ference
EN 55022 Class A Yes
FCC 47 CFR Part 15 Class A Yes
TP port
Length of a twisted pair segment max. 100 m / 300 ft (cat5e cable with 1000BASE-T)
Table 4: TP port 10BASE-T / 100BASE-TX / 1000BASE-T
Product
code
M-FAST-
SFP-...
Wave-
length
Fiber System at-
tenuation
Example
for fiber
optic line
length
Fiber data
-MM/LC... MM 1310 nm 50/125 µm 0-11 dB 0-5 km 1.0 dB/km, 800 MHz*km
-MM/LC... MM 1310 nm 62.5/125 µm 0-8 dB 0-4 km 1.0 dB/km, 500 MHz*km
-SM/LC... SM 1310 nm 9/125 µm 0-13 dB 0-25 km 0.4 dB/km; 3.5 ps/(nm*km)
-SM+/
LC...
SM 1310 nm 9/125 µm 10-29 dB 25-65 km 0.4 dB/km; 3.5 ps/(nm*km)
-LH/LC SM 1550 nm 9/125 µm 10-29 dB 40-104 km 0.25 dB/km; 19 ps/(nm*km)
Table 5: Fiber port 100BASE-FX (SFP fiber optic Fast ETHERNET Transceiver)
Product
code
M-SFP-
...
Wave-
length
Fiber System at-
tenuation
Example
for fiber
optic line
length
Fiber data
-SX/LC... MM 850 nm 50/125 µm 0-7.5 dB 0-550 m 3.0 dB/km, 400 MHz*km
-LX/LC... MM 1310 nm
a
a. With F/O adapter compliant with IEEE 802.3-2002 clause 38 (single-mode fiber offset-
la
unch mode conditioning patch cord)
50/125 µm 0-11 dB 0-550 m 1.0 dB/km, 800 MHz*km
-SX/LC... MM 850 nm 62.5/125 µm 0-7.5 dB 0-275 m 3.2 dB/km, 200 MHz*km
-LX/LC... MM 1310 nm
a
62.5/125 µm 0-11 dB 0-550 m 1.0 dB/km, 500 MHz*km
-LX/LC... SM 1310 nm 9/125 µm 0-11 dB 0-20 km 0.4 dB/km; 3.5 ps/(nm*km)
-LH/LC... LH 1550 nm 9/125 µm 6-22 dB 24-72 km 0.25 dB/km; 19 ps/(nm*km)
-LH+/LC LH 1550 nm 9/125 µm 15-32 dB 60-120 km 0.25 dB/km; 19 ps/(nm*km)
Table 6: Fiber port 1000BASE-FX (SFP fiber optic Gigabit ETHERNET Transceiver)
EMC interference
immunity

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
