Hirschmann RS20 User Manual

Entering the IP Parameters
Basic Configuration
Release 6.0 07/2010
2.2 Entering IP parameters via CLI
35
After entering the IP parameters, you can easily configure the device via the
Web-based interface (see the “Web-based Interface” reference manual).
enable Switch to the Privileged EXEC mode.
network protocol none Deactivate DHCP.
network parms 10.0.1.23
255.255.255.0
Assign the device the IP address 10.0.1.23 and
the netmask 255.255.255.0. You have the option
of also assigning a gateway address.
copy system:running-config
nvram:startup-config
Save the current configuration to the non-volatile
memory.

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
