Hirschmann RS20 User Manual

Loading Software Updates
Basic Configuration
Release 6.0 07/2010
4.3 Loading the software from the tftp
server
71
 Enter the path of the device software.
 Click on "Update" to load the software from the tftp server to the
device.
Figure 19: Software update dialog
 After successfully loading it, you activate the new software: Select
the dialog Basic Settings:Restart and perform a cold start.
In a cold start, the device reloads the software from the non-volatile
memory, restarts, and performs a self-test.
 After booting the device, click "Reload" in your browser to access the
device again.
enable Switch to the Privileged EXEC mode.
copy tftp://10.0.1.159/
rsL2E.bin system:image
Transfer the "rsL2E.bin" software file to the device
from the tftp server with the IP address 10.0.1.159.

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
