Hirschmann RS20 User Manual

Protection from Unauthorized Access
92
6.5 HiDiscovery Access
Basic Configuration
Release 6.0 07/2010
 Configure the port security.
 Select the Security:Port Security dialog.
 In the “Configuration” frame, select “IP-Based Port Security”.
 In the table, click on the row of the port to be protected, in the
“Allowed IP addresses” cell.
 Enter in sequence:
– the IP subnetwork group: 10.0.1.228
– a space character as a separator
– the IP address: 10.0.1.229
Entry:
10.0.1.228 10.0.1.229
 In the table, click on the row of the port to be protected, in the
“Action” cell, and select portDisable.
Figure 23: Port Security dialog

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
