1. GETTING STARTED
1-9
Table 1-1 Function of Each Part (2/5)
Name
Function
AC inlet
Used for connecting a power cord.
Power supply
A power supply module with a wide-range input voltage (100 to 240
VAC).
Main power switch
If you press the switch to the 1 position, the power is supplied. If you press
the switch to the 0 position, the power is shut down.
Audio port (LINE IN)
An audio line input.
Audio port (LINE OUT)
An audio line output.
Serial port (COM1)
(9 pins: RS-232C)
Connects a device such as a modem that uses a serial interface.
(See “5.9.1 Connector specifications”.)
Serial port (COM2)
(9 pins: RS-232C)
(optional)
Connects a device such as a modem that uses a serial interface.
(See “5.9.1 Connector specifications”.)
RAS external contact port
(25 pins: EXT)
(optional)
A connector for connecting external contacts. (See “5.9.1 Connector
specifications”.)
DVI-D port (Port A)
Connects the cable from the digital interface of a display. (See “5.9.1
Connector specifications”.)
DVI-D port (Port B)
Connects the cable from the digital interface of a display. (See “5.9.1
Connector specifications”.)
DisplayPort
Connects the cable from the digital interface of a display. (See “5.9.1
Connector specifications”.)
PCI Express x4 bus slot
(Slot 1)
The internal connection is PCI Express x4, but the connector shape is PCI
Express x8. However, Slot 1 cannot be used because the RAID board is
installed.
PCI Express x4 bus slot
(Slot 2) (Slot 3)
Used as a slot to insert a PCI Express x4 board.
PCI Express x16 bus slot
(Slot 4)
Used as a slot to insert a PCI Express x16 board.
PCI Express x1 bus slot
(Slot 5)
The internal connection is PCI Express x1, but the connector shape is PCI
Express x4.
PCI bus slot
(Slot 6) (Slot 7)
Used as a slot to insert a PCI board.
USB port (USB3.0)
Used to connect a device that uses a USB interface.
USB port (USB2.0)
Used to connect a device that uses a USB interface.
