4 - 9
2. The figure below shows an external view of a specimen stub (one set).
Figure 4.2.2-1 External View of the Specimen Stub
NOTE
: When handling the specimen stub, wear clean gloves to keep the specimen stub
free from particles and contaminants.
3. To the specimen stub, attach a conducting double-sided tape.
Figure 4.2.2-2 Attaching a Conducting Double-sided Tape to the Specimen Stub
NOTE
: With water-rich specimens, such as organisms, plants, and food items, use glue or
woodwork bond in small amounts. Set them in the specimen chamber after they
have become thoroughly dry.
Specimen stub
Height adjustment screw
lock nut 1
lock nut 2
