92
Galaxy 2 Series Installation Manual
Menu 60 - Engineer 2 Options
Option 61 - Diagnostics
This option allows the engineer to interrogate the system, providing valuable information on the operational
status of the Galaxy 2 Series and connected peripherals. The Galaxy polls each peripheral and reports the
successful communications during this period as a percentage.
There are seven sub-options. On selecting each of the sub options, the display shows the first of that type of
peripheral that is configured to the system. The scroll keys can be used to view additional peripherals of that
type if more than one is present.
1 = Keypads
This gives the module type, address and the communication level between the Galaxy 2 series panel and the
keypads.
2 = Zone RIO’s
This gives the module type, address and the communication level between the Galaxy 2 Series panel and the
zone RIO’s.
3 = RF Modules
This gives the module type, address and the communication level between the Galaxy 2 Series panel and the
RF Transceivers. In addition, pressing the # key gives two more screens; the RF noise level along with the
maximum noise level.
NOTE: 5800 series receivers do not give the above information.
4 = Prox Readers
This gives the module type, address and the communication level between the Galaxy 2 Series panel and the
prox readers.
5 = PSU’s
This gives the module type, address and the communication level between the Galaxy 2 Series panel and the
SPSU’s.
6 = Reset Max/Min
This sub-option allows the engineer to clear all the saved max/min information used in the diagnostics of the
PSU, Zones (hardwire and wireless) and the max noise level on the receivers. The message WARNING!!!
ent=RESET is displayed on the keypad before the reset takes place.
7 = GSM
This gives the module type, address and communication level between the Galaxy 2 Series panel and the
GSM module.
61 - Diagnostics
