93
Galaxy 2 Series Installation Manual
The Galaxy 2 Series polls each module 32 times every second and reports the successful communications
during this period as a percentage. This is calculated by the ratio of successful poll responses received from
each module. Typical figures are:
• 70% and above - satisfactory communication level
• 50 - 69% - Module requires monitoring
• 49% and below - remedial action required
Option 62 - Full Test
This menu option allows the engineer to test the bells and signalling on a busy occupied site. This is achieved
by simulating a full set but only making one or two zones active. The rest of the zones in the intruder system
are omitted for the duration of the test.
On entering the option, the engineer is presented with a display to choose a zone for the test. The first zone
that the user has access to is shown on the top row and the cursor keys can scroll through all the zones.
1025 Intruder1025 Intruder
1025 Intruder1025 Intruder
1025 Intruder
ENT=STARTENT=START
ENT=STARTENT=START
ENT=START
Top row alternates with descriptor
Pressing enter will select the zone shown for test.
The system will then ask for a second confirm zone. The cursor key selects yes or no.
2nd Confirm Zone2nd Confirm Zone
2nd Confirm Zone2nd Confirm Zone
2nd Confirm Zone
A=Yes B=NOA=Yes B=NO
A=Yes B=NOA=Yes B=NO
A=Yes B=NO
If Yes is selected, the system will allow the user to select a second zone in the same way as the first. If the
engineer selects NO or when the second zone is selected, the system omits all other intruder system zones and
sets instantly (no exit delay). All signalling and sounder activations will be as per a full set. The system is unset
in the normal manner.
62 - Full Test
Table 27. Diagnostic Module Information
eludoMcirteM
epyTeludoMsserddAsmmoC%leveLesioNleveLesioNxaM
sdapyeK
333
srednapxE
333
sreviecsnarT
3333 3
xorP
333
s'USP
333
MSG
333
For each peripheral, the following information is displayed where available:
