Galaxy 2 Series Installation Manual
09:04 SAT 01 JAN09:04 SAT 01 JAN
09:04 SAT 01 JAN09:04 SAT 01 JAN
09:04 SAT 01 JAN
Full Set usr 04Full Set usr 04
Full Set usr 04Full Set usr 04
Full Set usr 04
09:51 SAT 01 JAN09:51 SAT 01 JAN
09:51 SAT 01 JAN09:51 SAT 01 JAN
09:51 SAT 01 JAN
LOUNGELOUNGE
LOUNGELOUNGE
LOUNGE
09:04 SAT 01 JAN09:04 SAT 01 JAN
09:04 SAT 01 JAN09:04 SAT 01 JAN
09:04 SAT 01 JAN
Full Set A12--Full Set A12--
Full Set A12--Full Set A12--
Full Set A12--
Additional Info with # Key
Menu 20 - Display Options
Option 21 - Zone Status
This option shows the status of each zone on the system one at a time. The scroll keys scroll along the zone
list. For each zone, the zone type and its open/close/tamper status are displayed. If the # key is pressed, the
resistance reading for that zone is displayed, if hard-wired, or the last recorded signal strength if it is RF (from
Wireless Receiver on RS485 line only). There are two readings, one from each receiver, eg. 10/10.
NOTE: 5800 series detectors will not show signal strength.
Option 22 - View Log
The log is a 384 event capacity log which stores all the mandatory and optional events as required by
EN50131-1.
If group mode is enabled (refer to option 63 = OPTIONS), users are given group choice of group in View
Log. The available groups are displayed for selection. Press the number of the groups to be displayed, the N
below the selected group changes to a flashing Y. Press * to enable all groups simultaneously. When all the
required groups are selected press the ent key to access the log; only the events in the selected groups are
displayed.
The most recent event is displayed first. The user can scroll through events with single presses of the scroll
buttons. Holding the buttons down will scroll the log by one full day. While this is happening, the date is dis-
played and scrolls at one-second intervals.
The typical display for each event is as follows;
Standard Display
Display Options
NOTE: During any set period, if a particular event constantly repeats, only the first three occurences are
logged. The counter is reset when the panel rearms or is unset.
09:51 SAT 01 JAN09:51 SAT 01 JAN
09:51 SAT 01 JAN09:51 SAT 01 JAN
09:51 SAT 01 JAN
1021+1021+
1021+1021+
1021+
IntruderIntruder
IntruderIntruder
Intruder
Event time
Date
Event
Source
Event
Type
