Galaxy 2 Series Installation Manual
52 - Zones (cont’d)
Table 23. Zone Functions and Descriptions
noitcnuFenoZ noitpircseD
0evitcAtoN .derotinomerasrepmattubsmralanievitcatonsienoZ.testraPniesuroF
1laniF
gn
ittesetanimretyamgnittesgnirudnoitavitcA.erudecorpyrtnedemitehtsetaitinitestslihwnoitavitcA
.sdnoces54
otemityrtneehtstesnoitcnufehtni*gnisserP.gnimmargorpnognidneped
2tixE .serudecorpgnittesnudemitdnagnitte
sehtgnirudevitcanisihcihwenozredurtnI
3redurtnI.tesnehwmralaredurtnitnatsninasesuaC
4sruoH42.evitcayltnenam
reptubenozredurtninasA
8teShsuP.erudecorpgnittesasetanimreT
9hctiwsyeK .resu2levelsetalumiS.tesnusesuacdeso
lcotnoitisnarT.gnittessetaitininepootnoitisnarT
31AP.mralaAPasetavitcA
41tneliSAP.mralaAPtnelisasetavitcA
71k
niL.skniletavitcaotdesuebnactubnoitcnufmralaonsaH
81erapS .yrettabwoLFRdnanoisivrepusFR,srepmatgnidulcni,
evitcanienozralucitrapafonoitcnufllasredneR
91eriF.mralaerifasetavitcA
02repmaT
nitluserenozehtfoetatsrepma
tlacisyhpdnaetatsmralalacisyhpehthtob(noitidnocrepmatasetavitcA
.)noitavitcarepmatemaseht
32liaFttaB.noit
idnoctluafSPAnasesuaC
52liaFCA.tluafSPPasesuaC
35yrtnEyradnoceS
fostnemeriuqerehtrepsa,enozlaniFafognittimo
ecrofehtnopuyrtneotsegnahctubnoitcnuftixEsA
.342DD
45ecnatsissA.mralaecnatsissAnasetavitcA
55liaFlleBnoitidn
octluafllebasesuaC
02 Exit
Zones that protect the entry and exit routes are programmed as Exit. During the setting and unsetting proce-
dures Exit zones have a non-alarm operation. If the Exit zone is activated while the system is set - without the
unsetting of the group being initiated - an Intruder alarm condition is activated.
Opening an Exit zone during the exit time is not reported on the keypad as an open zone; the Entry/Exit
Horns bleep rapidly to indicate that the zone is open.
03 Intruder
The Intruder function is inactive when the system is unset. When the system is set, activation of an Intruder
zone causes a full alarm activation that requires to be reset with an authorized code.
04 24 Hours
As an intruder zone but permanently active.
NOTE: In the unset state, a 24 hour alarm is signalled. In the set state, an intruder alarm is signalled.
08 Push Set
This zone function is used to terminate the setting routine. The system sets when the Push Set zone, usually a
push button, is activated. The Entry/Exit Horn stops immediately the button is pressed; the system sets after
four seconds, allowing the doors to settle to the closed state. The Push Set zone remains inactive until the
next setting routine.
Only a Push Set zone in the common area will cause all setting areas to set, otherwise it will only set in the
area it is in. This will leave the other setting areas to continue setting until a Push Set zone in their area opens
and closes.
