Page 3-21
ANGLE (planar and solid angle measurements)
o
(sexagesimal degree), r (radian), grad (grade), arcmin (minute of arc), arcs
(second of arc), sr (steradian)
LIGHT (Illumination measurements)
fc (footcandle), flam (footlambert), lx (lux), ph (phot), sb (stilb), lm (lumem), cd
(candela), lam (lambert)
RADIATION
Gy (gray), rad (rad), rem (rem), Sv (sievert), Bq (becquerel), Ci (curie), R
(roentgen)
VISCOSITY
P (poise), St (stokes)
Units not listed
Units not listed in the Units menu, but available in the calculator include: gmol
(gram-mole), lbmol (pound-mole), rpm (revolutions per minute), dB (decibels).
These units are accessible through menu 117.02, triggered by using
MENU(117.02) in ALG mode, or 117.02 ` MENU in RPN mode. The menu
will show in the screen as follows (use ‚˜to show labels in display):
These units are also accessible through the catalog, for example:
gmol: ‚N~„g
lbmol: ‚N~„l
rpm: ‚N~„r
dB: ‚N~„d
