HP 5130 EI series User Manual

105
Figure 37 System startup process
Upgrade methods
U
pg
radin
g
method Software t
yp
es Remarks
Upgrading from the CLI:
Upgrading software through a
reboot
• Boot ROM image
• Comware images
(excluding patches)
This method is disruptive. You must reboot the
entire device to complete the upgrade.
Upgrading from the Boot
menu
• Boot ROM image
• Comware software
images
Use this method when the device cannot start up
correctly.
IMPORTANT:
Upgrade an IRF fabric from the CLI rather than the
Boot menu.
The Boot menu method increases the service
downtime, because it requires that you upgrade
the member devices one by one.
This chapter only covers upgrading software from the CLI without using ISSU.
Non-ISSU upgrade procedure summary
To upgrade software from the CLI without using ISSU:
1. Download the upgrade software image file.
2. (Optional.) Preload the Boot ROM image to the Boot ROM.
If a Boot ROM upgrade is required, you can perform this task to shorten the subsequent upgrade
time. This task helps avoid upgrade problems caused by unexpected electricity failure.
Start
Finish
Press Ctrl+B
promptly?
Boot ROM runs
Startup software images
run
System starts up and CLI
appears
Enter Boot menus to
upgrade Boot ROM or
startup software
images
Yes
No

HP 5130 EI series Specifications

General

Layer	Layer 3
VLANs	4094
Multicast Protocols	IGMP, PIM
Operating Temperature	0°C to 45°C
Model	HP 5130 EI
Ports	24 or 48 10/100/1000 ports
Uplink Ports	4 x 1/10G SFP+
Stacking	Up to 9 switches
Power over Ethernet (PoE)	PoE+ (IEEE 802.3at) on PoE+ models (JG936A, JG937A)
Management	Web, CLI, SNMP
MAC Address Table Size	32, 000 entries
Routing Protocols	OSPF, RIP, BGP, static routing
Operating Humidity	10% to 90% (non-condensing)
