HP 5130 EI series User Manual

41
Figure 21 Network diagram
Configuration procedure
# Create an ACL to permit packets sourced from Host A and Host B.
<Sysname> system-view
[Sysname] acl number 2000 match-order config
[Sysname-acl-basic-2000] rule 1 permit source 10.110.100.52 0
[Sysname-acl-basic-2000] rule 2 permit source 10.110.100.46 0
[Sysname-acl-basic-2000] quit
# Associate the ACL with the SNMP community and the SNMP group.
[Sysname] snmp-agent community read aaa acl 2000
[Sysname] snmp-agent group v2c groupa acl 2000
[Sysname] snmp-agent usm-user v2c usera groupa acl 2000
Configuring command authorization
By default, commands are available for a user depending only on that user's user roles. When the
authentication mode is scheme, you can configure the command authorization function to further control
access to commands.
After you enable command authorization, a command is available for a user only if the user meets the
following conditions:
• Has the commensurate user role.
• Authorized to use the command by the AAA scheme.
This section provides the procedure for configuring command authorization. To make the command
authorization function take effect, you must configure a command authorization method in ISP domain
view. For more information, see Security Configuration Guide.
Configuration procedure
To configure command authorization:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A

HP 5130 EI series Specifications

General

Layer	Layer 3
VLANs	4094
Multicast Protocols	IGMP, PIM
Operating Temperature	0°C to 45°C
Model	HP 5130 EI
Ports	24 or 48 10/100/1000 ports
Uplink Ports	4 x 1/10G SFP+
Stacking	Up to 9 switches
Power over Ethernet (PoE)	PoE+ (IEEE 802.3at) on PoE+ models (JG936A, JG937A)
Management	Web, CLI, SNMP
MAC Address Table Size	32, 000 entries
Routing Protocols	OSPF, RIP, BGP, static routing
Operating Humidity	10% to 90% (non-condensing)
