HP 530 User Manual

5-53
General System Configuration
Configuring RADIUS Accounting
Figure 5-12. Configuring RADIUS Accounting Servers
To Set RADIUS Accounting Server Parameters:
1. Click Network Setup > WLANs.
2. Click the [Edit] button for the WLAN (BSS/SSID) interface you want to
modify.
3. A pop-up window with Security settings opens. Select the Accounting
Servers tab.
4. For the primary RADIUS Accounting server, enter the IP address in the IP
field. (The default is 0.0.0.0, which indicates disabled.).
5. In the Port field, specify the UDP port number used by the RADIUS
Accounting server. (The default is 1813.)
6. In the Secret Key field, specify the shared text string that is also used by
the RADIUS server.
7. (Optional) If you need to configure a secondary RADIUS Accounting
server in the network, specify its IP address and other parameters in the
appropriate fields. Otherwise, leave the IP address as all zeros (0.0.0.0).
8. Click [Update].
