HP 530 User Manual

8-11
Special Features
QoS Commands
This example uses the show qos commands to display QoS details on the
access point.
ProCurve Access Point 530# configure
ProCurve Access Point 530(config)# radio 1
ProCurve Access Point 530(radio1)# show qos ap-params
------------------------------------------------------------
Transmission Queue QoS Settings for the Access Point:
Radio 1 Adaptive Inter- Contention Contention Maximum Burst
Queue Frame Space Min. Window Max. Window Length
------------------------------------------------------------------------------
Voice 1 3 7 1.5
Video 1 7 15 3.0
Best-Effort 3 15 63 0
Background 7 15 1023 0
Radio 2 Adaptive Inter- Contention Contention Maximum Burst
Queue Frame Space Min. Window Max. Window Length
------------------------------------------------------------------------------
Voice 1 3 7 1.5
Video 1 7 15 3.0
Best-Effort 3 15 63 0
Background 7 15 1023 0
ProCurve Access Point 530(radio1)# show qos sta-params
Transmission queue QoS settings for wireless stations:
Radio 1 Adaptive Inter- Contention Contention Transmission
Queue Frame Space Min. Window Max. Window Opportunity Limit
------------------------------------------------------------------------------
Voice 2 3 7 47
Video 2 7 15 94
Best-Effort 3 15 1023 0
Background 7 15 1023 0
Radio 2 Adaptive Inter- Contention Contention Transmission
Queue Frame Space Min. Window Max. Window Opportunity Limit
------------------------------------------------------------------------------
Voice 2 3 7 47
Video 2 7 15 94
Best-Effort 3 15 1023 0
Background 7 15 1023 0
ProCurve Access Point 530(radio1)#
