HP 530 User Manual

8-21
Special Features
Wireless Distribution System (WDS) and Spanning Tree Protocol (STP)
Figure 8-7. Configuring WDS Link Parameters with WEP Security
To Configure WDS Link Parameters with WEP Security:
1. Select Special Features > WDS tab.
2. To enable a WDS link, choose Enabled for the specific link option.
3. To set the radio to establish the WDS link, use the Radio drop-down.
4. Enter the remote MAC Address or, if AP detection is enabled, select the
remote MAC Address from the drop-down of the access point to which
you are trying to establish the WDS link.
The Security mode is preconfigured when the WLAN Security is config-
ured. See
Table 7-4, “WLAN 1 and WDS Security Configuration,” on page 17.
5. Modify defaulted Key Length and Key Type, if necessary.
6. Enter the WEP Key, adhering to previous set key parameters.
7. Select [Update] to save the settings.

HP 530 Specifications

General

Graphics	Intel GMA 950
Processor	Intel Core Duo T2050
RAM	512 MB, upgradable to 2 GB
Storage	80 GB HDD
Display	15.4-inch WXGA (1280 x 800)
Operating System	Windows XP Professional
Battery	6-cell Lithium-Ion
Optical Drive	DVD+/-RW
Ports	3 x USB 2.0, 1 x VGA, 1 x RJ-45, 1 x RJ-11, 1 x Headphone, 1 x Microphone
Wireless	802.11a/b/g
