Changing Your Workstation’s Hardware Configuration
Installing Storage Devices
4 From the front of the storage tray, line up the disk slides on the floppy drive with
the position 2 slots in the storage tray chassis and slide it into place, as shown in
Figure 31.
Figure 31 Installing a Floppy Drive
5 Push the floppy drive in until the locking tabs snap into place.
6 Proceed to the section entitled Replacing the Storage Tray.
Cable Routing Label
