Product Information
System Unit Rear Panel Connectors
SCSI Connectors
Use the SCSI connectors to connect external SCSI devices such as DDS-for-
mat tape drives and CD-ROM drives. Consult the documentation that
accompanies each SCSI device for specific information concerning its use.
Refer to Appendix C of this manual for information about connecting SCSI
devices to your workstation.
NOTICE: There must ALWAYS be a terminator at both ends of a SCSI bus. This
means one internal terminator and one external terminator. Both the FW
SCSI and SE SCSI connectors must have a terminator connected when no
external device is connected.
TOC Button
The TOC button resets the system and transfers control from the default
device to an auxiliary device.
Power Cord Connector
Plug the workstation’s power cord into the power cord connector to provide
ac power to the system.
