Product Information
System Unit Rear Panel Connectors
Figure 7 System Unit Rear Panel Connectors
Pullout Card
The pullout card contains serial and model number information along with
regulatory agency information.
Security Loop
The security loop provides a means of locking the storage tray with a pad-
lock or other locking device, to prevent unauthorized removal from the sys-
tem.
Audio Line In
PS/2 Mouse
PS/2 Keyboard
HP Parallel
LAN-AUI
LAN-TP
Serial 1
Serial 2
Single-Ended SCSI
Fast, Wide SCSI
Audio Line Out
Power
Security Loop
