Product Information
System Unit Front Panel Controls
DDS Tape Drive
Your DDS tape drive is either a DDS-DC (early or later model) or a DDS-2
tape drive with a 3.5-inch form factor, data compression, and a single-ended
SCSI interface. Both drives incorporate data compression capability and are
high-capacity, high transfer-rate devices for data storage on tape. With com-
pression, the DDS-DC drives can store up to 4 GB of data on a 90 meter tape
and the DDS-2 drive can store up to 8 GB of data on a 120 meter tape.
Figure 3, Figure 4, and Figure 5 show the LEDs, and eject button of the
DDS-format tape drives.
Figure 3 DDS-DC (Early Model) Drive Controls and Indicators
Figure 4 DDS-DC (Later Model) Drive Controls and Indicators
Cassette LED Drive LED Eject Button
Tape LED Clean/Attention LED Eject Button
Tape Clean
DCLZ
