SCSI Connections
SCSI Restrictions
CAUTION: Do not mix SE SCSI and FW SCSI peripherals on the same SCSI bus.
FW SCSI Bus Configuration Constraints
FW SCSI does not work with the SE SCSI.
Table 23 shows the configuration constraints for each FW SCSI device type.
CAUTION: Do not mix single-ended, fast differential, and fast, wide SCSI peripherals together
on the same bus.
Table 23 FW SCSI Bus Configuration Constraints
FW SCSI Devices
Maximum Number of Each Type
of Device Allowed
FW SCSI Disk Drive (up to 3 internal) 15
Fast, Wide SCSI Disk Arrays (addressed as single
drive)
7
