Changing Your Workstation’s Hardware Configuration
Installing an EISA, PCI, or GSC Option Board
Graphics Paths
graphics(0) is the built-in 8-plane graphics adapter.
graphics(1) and graphics(2) are graphics adapters installed in option slots 1
and 2.
When a dual display graphics adapter (an adapter which has two video out-
put connectors) is installed, the video connector on the left (when looking at
the system from the rear) is graphicsNA and the video connector on the right
is graphicsNB, where N is the slot number in which the graphics adapter is
installed.
For example, a Dual Visualize Enhanced Graphics Card (A4451A) installed
in option slot 2 would be graphics(2A) and graphics(2B).
