Changing Your Workstation’s Hardware Configuration
Installing an EISA, PCI, or GSC Option Board
Installing an EISA, PCI, or GSC Option Board
Your workstation has 4 option slots, as shown in Figure 51. Slots 1 and 2
support GSC or EISA boards, slot 3 supports EISA or PCI boards, and slot 4
supports only PCI boards..
Figure 51 Option Slots from Outside the System Unit
Slot 1 Slot 2 Slot 3 Slot 4
